Volume 44 Issue 4
Aug.  2023
Turn off MathJax
Article Contents
Li Nali, Zhang Renjie. Effect of glucose content on the lithium storage performance of Li3V2(PO4)3/C cathode materials prepared by sol-gel combustion method[J]. IRON STEEL VANADIUM TITANIUM, 2023, 44(4): 41-47. doi: 10.7513/j.issn.1004-7638.2023.04.006
Citation: Li Nali, Zhang Renjie. Effect of glucose content on the lithium storage performance of Li3V2(PO4)3/C cathode materials prepared by sol-gel combustion method[J]. IRON STEEL VANADIUM TITANIUM, 2023, 44(4): 41-47. doi: 10.7513/j.issn.1004-7638.2023.04.006

Effect of glucose content on the lithium storage performance of Li3V2(PO4)3/C cathode materials prepared by sol-gel combustion method

doi: 10.7513/j.issn.1004-7638.2023.04.006
  • Received Date: 2023-04-19
  • Publish Date: 2023-08-30
  • In this paper, submicrometer porous Li3V2(PO4)3 (LVP)/C composites with different carbon contents were successfully prepared by a modified sol-gel combustion method by changing the amount of glucose added. The effects of glucose addition on the structure, morphology and electrochemical properties of LVP were systematically studied. Although the addition of glucose did not change the crystal structure and lattice parameters of LVP, nanoneedle-like particles appeared in the samples with glucose, which were beneficial to electron transport and Li+ diffusion. With the increase of glucose content, the volume fraction of nanoneedle-like particles increased, thus improving the rate performance of LVP/C cathode materials. The amorphous carbon generated by carbonization of glucose is evenly coated on the surface of LVP particles, which improves the conductivity of the composites. The conductivity increases with the increase of glucose content. However, excessive glucose addition will lead to too thick carbon coating, which is not conducive to the transmission of Li+. Benefiting from the appropriate amount of glucose addition, nanoneedle-like particles and porous structure, LVP/C-G15% sample has excellent lithium storage performance. It can still provide a discharge specific capacity of 75.1 mAh/g after 200 cycles at a high rate of 10 C, and the capacity retention rate is as high as 89.0%.
  • loading
  • [1]
    Sun Chunwen, Rajasekhara Shreyas, Dong Youzhong, et al. Hydrothermal synthesis and electrochemical properties of Li3V2(PO4)3/C-based composites for lithium-ion batteries[J]. ACS Applied Materials & Interfaces, 2011,3(9):3772−3776.
    Membreño Nellymar, Park Kyusung, Goodenough John B, et al. Electrode/electrolyte interface of composite α-Li3V2(PO4)3 cathodes in a nonaqueous electrolyte for lithium ion batteries and the role of the carbon additive[J]. Chemistry of Materials, 2015,27(9):3332−3340. doi: 10.1021/acs.chemmater.5b00447
    Membreño Nellymar, Xiao Penghao, Park Kyu Sung, et al. In situ Raman study of phase stability of α-Li3V2(PO4)3 upon thermal and laser heating[J]. The Journal of Physical Chemistry C, 2013,117(23):11994−12002. doi: 10.1021/jp403282a
    Yin S C, Strobel P S, Grondey H, et al. Li2.5V2(PO4)3:   A room-temperature analogue to the fast-ion conducting high-temperature γ-phase of Li3V2(PO4)3[J]. Chemistry Of Materials, 2004,16(8):1456−1465. doi: 10.1021/cm034802f
    Peng Yi, Tan Rou, Ma Jianmin, et al. Electrospun Li3V2(PO4)3 nanocubes/carbon nanofibers as free-standing cathodes for high-performance lithium-ion batteries[J]. Journal of Materials Chemistry A, 2019,7(24):14681−14688. doi: 10.1039/C9TA02740H
    Tan Huiteng, Xu Lianhua, Geng Hongbo, et al. Nanostructured Li3V2(PO4)3 cathodes[J]. Small, 2018,14(21):1800567. doi: 10.1002/smll.201800567
    Cui Kai, Hu Shuchun, Li Yongkui. Nitrogen-doped graphene nanosheets decorated Li3V2(PO4)3/C nanocrystals as high-rate and ultralong cycle-life cathode for lithium-ion batteries[J]. Electrochimica Acta, 2016,210:45−52. doi: 10.1016/j.electacta.2016.05.099
    Mohanty Debabrata, Lu Zhenlun, Hung I Ming. Effect of carbon coating on electrochemical properties of Nitrogen-doped graphene cathode synthesized by citric-acid gel method for lithium-ion batteries[J]. Journal of Applied Electrochemistry, 2023,53(5):1003−1013. doi: 10.1007/s10800-022-01828-1
    Chen Jian, Zhao Na, Guo Feifan. Impact of carbon coating thickness on the electrochemical properties of Li3V2(PO4)3/C composites[J]. Russian Journal of Electrochemistry, 2017,53(4):339−344. doi: 10.1134/S102319351704005X
    Zhou Ji, Sun Xinyu, Wang Kai. Preparation of high-voltage Li3V2(PO4)3 co-coated by carbon and Li7La3Zr2O12 as a stable cathode for lithium-ion batteries[J]. Ceramics International, 2016,42(8):10228−10236. doi: 10.1016/j.ceramint.2016.03.144
    Han Hui, Qiu Feng, Liu Zhentao, et al. ZrO2-coated Li3V2(PO4)3/C nanocomposite: A high-voltage cathode for rechargeable lithium-ion batteries with remarkable cycling performance[J]. Ceramics International, 2015,41(7):8779−8784. doi: 10.1016/j.ceramint.2015.03.103
    Liao Yuxing, Li Chao, Lou Xiaobing, et al. Carbon-coated Li3V2(PO4)3 derived from metal-organic framework as cathode for lithium-ion batteries with high stability[J]. Electrochimica Acta, 2018,271:608−616. doi: 10.1016/j.electacta.2018.03.100
    Chen Yueqian, Xiang Kaixiong, Zhu Yirong, et al. Porous, nitrogen-doped Li3V2(PO4)3/C cathode materials derived from oroxylum and their exceptional electrochemical properties in lithium-ion batteries[J]. Ceramics International, 2019,45(4):4980−4989. doi: 10.1016/j.ceramint.2018.11.198
    Sun Hongxia, Du Haoran, Yu Mengkang, et al. Vesicular Li3V2(PO4)3/C hollow mesoporous microspheres as an efficient cathode material for lithium-ion batteries[J]. Nano Research, 2019,12(8):1937−1942. doi: 10.1007/s12274-019-2461-1
    Lee Hwang Sheng, Ramar Vishwanathan, Kuppan Saravanan, et al. Key design considerations for synthesis of mesoporous α-Li3V2(PO4)3/C for high power lithium batteries[J]. Electrochimica Acta, 2021,372:137831. doi: 10.1016/j.electacta.2021.137831
    Zhang Le, Xiang Hongfa, Li Zhong, et al. Porous Li3V2(PO4)3/C cathode with extremely high-rate capacity prepared by a sol-gel-combustion method for fast charging and discharging[J]. Journal of Power Sources, 2012,203:121−125. doi: 10.1016/j.jpowsour.2011.11.082
    Ou Qingzhu, Tang Yan, Zhong Yanjun, et al. Submicrometer porous Li3V2(PO4)3/C composites with high rate electrochemical performance prepared by sol-gel combustion method[J]. Electrochimica Acta, 2014,137:489−496. doi: 10.1016/j.electacta.2014.04.178
    Taddesse Paulos, Belete Birhanu. Substitutional effect on structural, electrical and electrochemical behaviors of LiMn1.977(Ce, Cu)0.023O4 nanoparticles prepared by sol-gel combustion method[J]. Chemical Physics, 2019,522:260−266. doi: 10.1016/j.chemphys.2019.03.015
    Li Nali, Tong Yanwei, Yi Dawei, et al. Facile synthesis of Li3V2(PO4)3/C composite with a complex morphology and its excellent electrochemical performance as cathode material for lithium ion batteries[J]. Materials Research Express, 2019,6(11):115530. doi: 10.1088/2053-1591/ab49c1
    Li Nali, Yu Yong, Tong Yanwei, et al. Sc3+-doping effects on porous Li3V2(PO4)3/C cathode with superior rate performance and cyclic stability[J]. Ceramics International, 2021,47(24):34218−34224. doi: 10.1016/j.ceramint.2021.08.331
    Li Nali, Tong Yanwei, Yi Dawei, et al. Effect of Zr4+ doping on the morphological features and electrochemical performance of monoclinic Li3V2(PO4)3/C cathode material synthesized by an improved sol-gel combustion technique[J]. Journal of Alloys and Compounds, 2021,868:158771. doi: 10.1016/j.jallcom.2021.158771
    Li Ruhong, Liu Jianchao, Chen Tianrui, et al. Systematic evaluation of lithium-excess polyanionic compounds as multi-electron reaction cathodes[J]. Nanoscale, 2019,11(36):16991−17003. doi: 10.1039/C9NR05751J
    Yu Shicheng, Mertens Andreas, Kungl Hans, et al. Morphology dependency of Li3V2(PO4)3/C cathode material regarding to rate capability and cycle life in lithium-ion batteries[J]. Electrochimica Acta, 2017,232:310−322. doi: 10.1016/j.electacta.2017.02.136
    Chen Lin, Yan Bo, Xu Jing, et al. Bicontinuous structure of Li3V2(PO4)3 clustered via carbon nanofiber as high-performance cathode material of Li-ion batteries[J]. ACS Applied Materials & Interfaces, 2015,7(25):13934−13943.
    Yu Shicheng, Mertens Andreas, Schierholz Roland, et al. An advanced all phosphate lithium-ion battery providing high electrochemical stability, high rate capability and long-term cycling performance[J]. Journal of the Electrochemical Society, 2017,164:A370−A379. doi: 10.1149/2.1151702jes
    Xiong Fangyu, Tan Shuangshuang, Wei Qiulong, et al. Three-dimensional graphene frameworks wrapped Li3V2(PO4)3 with reversible topotactic sodium-ion storage[J]. Nano Energy, 2017,32:347−352. doi: 10.1016/j.nanoen.2016.12.050
    Guo Shuainan, Bai Ying, Geng Zhenfeng, et al. Facile synthesis of Li3V2(PO4)3 cathode material for lithium-ion battery via freeze-drying[J]. Journal of Energy Chemistry, 2019,32:159−165. doi: 10.1016/j.jechem.2018.07.011
    Rui Xianhong, Yan Qingyu, Skyllas Kazacos Maria, et al. Li3V2(PO4)3 cathode materials for lithium-ion batteries: A review[J]. Journal of Power Sources, 2014,258:19−38. doi: 10.1016/j.jpowsour.2014.01.126
    Oh Woong, Park Hyunyoung, Jin Bong-Soo, et al. Understanding the structural phase transitions in lithium vanadium phosphate cathodes for lithium-ion batteries[J]. Journal of Materials Chemistry A, 2020,8(20):10331−10336. doi: 10.1039/C9TA12435G
    Ruan Tingting, Lu Shengli, Lu Junyang, et al. Unraveling the intercalation chemistry of multi-electron reaction for polyanionic cathode Li3V2(PO4)3[J]. Energy Storage Materials, 2023,55:546−555. doi: 10.1016/j.ensm.2022.12.021
    Bi Linnan, Song Zhicui, Liu Xiaoqin, et al. Critical roles of RuO2 nano-particles in enhancing cyclic and rate performance of Lisicon Li3V2(PO4)3 cathode materials[J]. Journal of Alloys and Compounds, 2020,845:156271. doi: 10.1016/j.jallcom.2020.156271
    Zhang Shu, Gu Qin, Tan Shan, et al. Improved electrochemical properties of the Li3V2(PO4)3 cathode material synthesized from a V(III) precursor[J]. Journal of Alloys and Compounds, 2019,802:583−590. doi: 10.1016/j.jallcom.2019.06.240
