In-situ Observation on the Formation and Aggregation of Al2O3 Inclusions in Molten Steel
-
摘要: 利用高温激光共聚焦显微镜观察了铝脱氧钢Al2O3夹杂的生成、聚集成团簇以及Al2O3团簇运动到固液界面的行为特征,发现从生成单颗粒Al2O3并且单颗粒Al2O3从相距145μm到自发聚集成78μm的Al2O3团簇仅需1.5 s,聚集后的Al2O3团簇从钢液内悬浮位置被吸附移动146μm至固液界面仅需0.5 s,后续生成单颗粒Al2O3迅速向固液界面处的Al2O3团簇聚集,Al2O3团簇可在1 s时间由细长状收缩为团状。理论分析表明Al2O3夹杂聚集、Al2O3团簇被固液界面吸附的主要作用力为范德华力,且夹杂尺寸越大所受范德华力越大,夹杂物的移动速度越快,Al2O3团簇自发收缩成团主要是液桥力的作用。Abstract: The formation of Al2O3 inclusions,aggregation and movement of Al2O3 clusters to solid-liquid interface are observed by high temperature laser confocal microscopy.It is found outthat it takes only 1.5 s to form Al2O3 granulates and the Al2O3 granulates far from 145 μm apart gather into a 78 μm cluster spontaneously.It takes only 0.5 s for the aggregated Al2O3 cluster to be absorbed and moved from the suspension position in molten steel to the solid-liquid interface,the subsequently formed single Al2O3 particles are rapidly absorbed by the Al2O3 cluster,the Al2O3 cluster shrink to mass in 1 s.The theoretical analysis shows that the van der Waals force is the main force acting on the aggregation of Al2O3 inclusions and Al2O3 cluster adsorbed by solid-liquid interface,and the larger the size of inclusions.Greater the van der Waals force,results in faster movement of inclusions.The spontaneous shrinkage of Al2O3 clusters is mainly caused by the liquid bridge force.
-
Key words:
- aluminum deoxidation steel /
- Al2O3inclusions /
- cluster /
- van der Waals force /
- liquid bridge force
-
