Effects of EMS on the dendritic structure and homogeneity of rail steel
-
摘要: 为提升重轨钢均质性和致密性，通过试验对比分析连铸电磁搅拌对大方坯重轨钢凝固组织及均质性的影响。结果表明：无电磁搅拌工艺条件下，铸坯凝固组织无明显分区，枝晶组织致密且铸坯窄面至距离窄面80 mm区域的均质性较好，但铸坯中心偏析严重；通过取消结晶器电磁搅拌（M-EMS）并采用凝固末端电磁搅拌（F-EMS）有利于重轨钢均质性和致密性协同提升，试验铸坯中心偏析可以得到补充控制，铸坯轧制钢轨的中心偏析控制良好，轨头Mn元素偏析度极差达到0.098，致密度达到0.9764。Abstract: In order to optimize the homogeneity and compactness of rail steel, the effects of continuous casting electromagnetic stirring on the dendritic structure and homogeneity of rail steel was analyzed by industrial experiments. The results show that blooms produced without electromagnetic stirring have no obvious dendritic structure partition, the dendritic structure tends to be more compact and the homogeneity is better for the area in which from narrow surface to 80 mm below, while central segregation tends to be worse. The F-EMS is more suitable both for optimizing homogeneity and compactness than M-EMS. Central segregation control of experiment blooms could be make up, Central segregation of rails rolled from the experiment blooms is well, and the same as rail head, range value of segregation degree for Mn is 0.098, value of compactness degree is 0.9764.
-
Key words:
- continuous casting /
- rail steel /
- electromagnetic stirring /
- dendritic structure /
- homogeneity /
- compactness
-
图 1 凝固组织腐蚀检验取样示意
Figure 1. Schematic diagram of Sampling for dendritic structure corrosion testing
图 3 铸坯偏析检验的取样位置示意
Figure 3. Schematic diagram of sampling position for segregation testing of bloom
图 4 结晶器电磁搅拌强度对铸坯C元素偏析度的影响
Figure 4. Effect of mold electro-magnetic stirring intensity on carbon segregation degree of bloom
图 5 铸坯凝固组织检验取样示意
Figure 5. Schematic diagram of Sampling for dendritic structure corrosion testing
图 6 连铸电磁搅拌试验铸坯凝固组织的典型照片
Figure 6. Typical photograph of dendritic structure in bloom for continuous casting electro-magnetic stirring testing
图 8 钢轨轨头金属原位扫描检验区域
Figure 8. Testing area in rail head for scanning by metal In-situ analyzer
图 10 工艺验证试验钢轨腐蚀的典型低倍照片
Figure 10. Typical macro-photograph of rail for processes verification testing
表 1 不同试验工艺对应的实际磁场强度
Table 1. Actual magnetic flux density corresponding to the testing processes
T 试验工艺 实际磁场强度×10−4 强搅拌 350~400 弱搅拌 200~250 无搅拌 0
下载: 导出CSV
表 2 连铸电磁搅拌工艺验证试验方案
Table 2. Test program of processes verification for continuous casting electro-magnetic stirring
试验工艺 结晶器电磁搅拌
（M-EMS）凝固末端电磁搅拌
（F-EMS）工艺1 无 有 工艺2 有 无 工艺3 有 有
下载: 导出CSV
-
[1] Guo Xiaoyang. Research on the development trend of railway transportation in China[J]. Co-operative Economy & Science, 2012,(2):10−12. (郭晓阳. 我国铁路运输发展趋势研究[J]. 合作经济与科技, 2012,(2):10−12. doi: 10.3969/j.issn.1672-190X.2012.02.005 [2] (李春龙. 包钢高速铁路重轨钢生产工艺及质量水平[C]// 2008年全国炼钢——连铸生产技术会议文集.中国金属学会, 2008: 12.)Li Chunlong. Production technology and quality level of heavy rail steel for high-speed railway of Baotou steel[C]// Proceedings of Steel Making and Continuous Casting Technology Conference. Chinese Society for Metals, 2008: 12. [3] Li Pin, Wang Lei, Zhou Qingfeng. Formation reasons and countermeasures of cementite network in the center of 82B wire rods[J]. Journal of Iron and Steel Research, 2014,26(9):33−36. (李平, 王雷, 周青峰. 82B中心网状渗碳体产生原因及改善方法[J]. 钢铁研究学报, 2014,26(9):33−36. [4] （纪元. 连铸还偏析及其铸轧遗传性研究[D]. 北京: 北京科技大学, 2018.）Ji Yuan. Segregation of billet castings and its heredity effect on the hot-rolled products[D]. Beijing:University of Science and Technology Beijing, 2018. [5] Zong Nanfu, Zhang Hui, Liu Yang, et al. Causes and harms of defects in solidification structure and segregation of continuous casting bearing steel[J]. Bearing, 2018,(6):62−67. (宗男夫, 张慧, 刘洋, 等. 连铸轴承钢偏析和凝固组织缺陷的成因及其危害[J]. 轴承, 2018,(6):62−67. [6] Song Yancheng, Liu Jigang. Analyze of the effects of segregation on the performance of billets[J]. Modern Metallurgy, 2019,47(2):7−10. (宋延成, 刘吉刚. 偏析对于连铸坯性能的影响分析[J]. 现代冶金, 2019,47(2):7−10. [7] Chen Yuhui, Song Yancheng. Analyze of the effects of segregation on the mechanical capacity of slab[J]. Modern Metallurgy, 2018,46(5):13−15. (陈玉辉, 宋延成. 连铸坯偏析对钢板机械性能的影响分析[J]. 现代冶金, 2018,46(5):13−15. doi: 10.3969/j.issn.1005-6068.2018.05.004 [8] （廖建国. 热溶质对流对连铸坯宏观偏析影响分析[N]. 世界金属导报, 2019-03-12(B02).）Liao Jianguo. Analyze of the effects of hot solute convection on the macro-segregation of bloom[N]. World metal guide report, 2019-03-12(B02). [9] Chen Liang. Study on macro-segregation control of continuous casting billet in gear steel 20CrMnTiH[J]. Iron Steel Vanadium Titanium, 2019,40(4):110−115. (陈亮. 小方坯连铸20CrMnTiH齿轮钢宏观偏析控制[J]. 钢铁钒钛, 2019,40(4):110−115. [10] Wang Baofeng, Li Jianchao. Application of electromagnetic stirring technology in continuous casting[J]. Angang Technology, 2009,(1):1−5. (王宝峰, 李建超. 电磁搅拌技术在连铸生产中的应用[J]. 鞍钢技术, 2009,(1):1−5. doi: 10.3969/j.issn.1006-4613.2009.01.001 [11] Limoges J, Beitelman L, Bai Jing. The effect of secondary cooling intensity and mole electromagnetic stirring carbon segregation and solidification structure of high carbon steel[J]. Tianjin Metallurgy, 2002,(4):40−45. (J·里摩吉斯, L·贝特尔曼, 白静. 二次冷却和结晶器电磁搅拌对高碳钢碳偏析及其凝固结构的影响[J]. 天津冶金, 2002,(4):40−45. doi: 10.3969/j.issn.1006-110X.2002.04.014 [12] Xu Ruijun, Yan Huicheng, Wu Qinming, et al. Effect of M-EMS on carbon segregation of gear steel round bar rolled from rectangular bloom[J]. Iron Steel Vanadium Titanium, 2012,33(02):56−61. (徐瑞军, 颜慧成, 吴清明, 等. 结晶器电磁搅拌对矩形坯轧制大规格齿轮钢圆钢碳偏析行为的影响[J]. 钢铁钒钛, 2012,33(02):56−61. [13] Cao Hongfu. Effect of multiple electro-magnetic stirring on carbon segregation in continuous casting low carbon steel[J]. Special steel, 2010,31(2):38−39. (曹红福. 连铸复合电磁搅拌对低碳钢碳偏析的影响[J]. 特殊钢, 2010,31(2):38−39. doi: 10.3969/j.issn.1003-8620.2010.02.012 -
