GB/T 2965-2023《钛及钛合金棒材》标准解析

解晨; 马忠贤; 冯军宁; 李巍; 魏佳琦; 冯永琦; 胡志杰; 马佳琨; 庆达嘎; 王若飞

doi:10.7513/j.issn.1004-7638.2024.05.027

GB/T 2965-2023《钛及钛合金棒材》标准解析

doi: 10.7513/j.issn.1004-7638.2024.05.027

解晨^{1, 2,},
马忠贤^{1, 2},
冯军宁^{1, 2},
李巍¹,
魏佳琦²,
冯永琦^{1, 2},
胡志杰^{1, 2},
马佳琨^{1, 2},
庆达嘎^{1, 2},
王若飞¹

1.
宝鸡钛业股份有限公司, 陕西宝鸡 721014
2.
宝钛集团有限公司, 陕西宝鸡 721014

详细信息

作者简介:
解晨，1987年出生，男，陕西延安人，硕士，高级工程师，主要从事稀有金属标准化研究及材料加工，E-mail：xiechen@baoti.com

中图分类号: TF823,G255.54
计量
- 文章访问数: 931
- HTML全文浏览量: 370
- PDF下载量: 41
- 被引次数: 0
出版历程
- 收稿日期: 2024-04-12
- 网络出版日期: 2024-10-30
- 刊出日期: 2024-10-30

Interpretation on GB/T 2965-2023: Titanium and titanium alloy bars

Xie Chen^{1, 2
,},
Ma Zhongxian^{1, 2},
Feng Junning^{1, 2},
Li Wei¹,
Wei Jiaqi²,
Feng Yongqi^{1, 2},
Hu Zhijie^{1, 2},
Ma Jiakun^{1, 2},
Qing Daga^{1, 2},
Wang Ruofei¹

1.
Baoji Titanium Industry Company Limited, Baoji 721014, Shaanxi, China
2.
Baoti Group Company Limited, Baoji 721014, Shaanxi, China

摘要

摘要: 介绍了新版标准GB/T 2965-2023的修订原因和演变过程，并从标准的主要修订点，包含：术语和定义、产品分类、外形尺寸及其允许偏差、热处理制度、力学性能、试验方法、取样规定、检验结果的判定等相关内容进行了解析，为标准在后续生产、检验过程提供指导，从而对新版标准起到推广和宣贯的作用。
- 钛 /
- 钛合金 /
- 棒材 /
- 标准 /
- 解析
Abstract: In this paper the revision reasons and process evolution of new standard GB/T 2965-2023 had been briefed. And interpretation had been made on the following points such as terms and definition, product category, dimension and tolerance, heat treatment, mechanical properties, sampling and test result determination. It is hoped that this interpretation can provide guidance for production and inspection of the standard in the follow-up process.
- titanium /
- titanium alloy /
- bars /
- standard /
- analysis

HTML全文

表 1 新增钛及钛合金棒材室温拉伸性能

Table 1. Tensile properties of newly added titanium and titanium alloy bars at room temperature

牌号	抗拉强度（R_m）/MPa	规定塑性延伸强度（R_p0.2）/MPa	断后伸长率（A）/%	断面收缩率（Z）/%
TA1	≥370	≥250	≥20	≥30
TA2	≥440	≥320	≥18	≥30
TA3	≥540	≥410	≥15	≥25
TA5	≥685	≥585	≥13	≥25
TA18	≥620	≥518	≥12	≥25
TB6	≥1105	≥1035	≥8	≥15
TC17	≥1120	≥1030	≥7	≥16
TC18	1080～1280	≥1010	≥9	≥25
TC21	≥1100	≥1000	≥8	≥15
TC25	≥980		≥10	≥20

下载: 导出CSV

表 2 新增钛合金棒材高温力学性能

Table 2. Mechanical properties of newly added titanium alloy bars at elevated temperature

牌号	试验温度/ ℃	抗拉强度(R_m)/MPa	持久性能
牌号	试验温度/ ℃	抗拉强度(R_m)/MPa	试验应力(σ)/MPa	试验时间(t)/h
TA18	≥350	≥340	≥320	≥100
TA18	≥400	≥310	≥280	≥100
TC17	≥400	≥885	≥685	≥100
TC25	≥500	≥735	≥637	≥50

下载: 导出CSV

参考文献(22)

[1]	Zhang Pinghui, Wang Yongmei, Huang Yongguang, et al. GB/T 2965-2007 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 2008. (张平辉, 王永梅, 黄永光, 等. GB/T 2965-2007《钛及钛合金棒材》[S]. 北京: 中国标准出版社, 2008. Zhang Pinghui, Wang Yongmei, Huang Yongguang, et al. GB/T 2965-2007 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 2008.
[2]	Feng Junning, Xie Chen, Ma Zhongxian, et al. Analysis of standard GB/T 3620.1-2016: Designation and composition of titanium and titanium alloys[J]. Iron Steel Vanadium Titanium, 2022,43(2):192-196. (冯军宁, 解晨, 马忠贤, 等. GB/T 3620.1-2016《钛及钛合金牌号和化学成分》标准解析[J]. 钢铁钒钛, 2022,43(2):192-196. doi: 10.7513/j.issn.1004-7638.2022.02.029 Feng Junning, Xie Chen, Ma Zhongxian, et al. Analysis of standard GB/T 3620.1-2016: Designation and composition of titanium and titanium alloys[J]. Iron Steel Vanadium Titanium, 2022, 43（2）: 192-196. doi: 10.7513/j.issn.1004-7638.2022.02.029
[3]	Xie Chen, Feng Junning, Li Wei, et al. GB/T 2965-2023 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 2008. (解晨, 冯军宁, 李巍, 等. GB/T 2965-2023《钛及钛合金棒材》[S]. 北京: 中国标准出版社, 2008. Xie Chen, Feng Junning, Li Wei, et al. GB/T 2965-2023 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 2008.
[4]	YB 766-1970 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1970. (YB 766-1970《钛及钛合金棒材》[S]. 北京: 中国标准出版社, 1970. YB 766-1970 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1970.
[5]	Huang Liping. GB 2965-1982 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1982. (黄礼平. GB 2965-1982《钛及钛合金棒材》[S]. 北京: 中国标准出版社, 1982. Huang Liping. GB 2965-1982 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1982.
[6]	Huang Liping, Jin Shuangfeng. GB 2965-1987 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1987. (黄礼平, 金双凤. GB 2965-1987《钛及钛合金棒材》[S]. 北京: 中国标准出版社, 1987. Huang Liping, Jin Shuangfeng. GB 2965-1987 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1987.
[7]	Huang Liping, Feng Yinglei, Gui Jun, et al. GB/T 2965-1996 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1996. (黄礼平, 冯英雷, 归军, 等. GB/T 2965-1996《钛及钛合金棒材》[S]. 北京: 中国标准出版社, 1996. Huang Liping, Feng Yinglei, Gui Jun, et al. GB/T 2965-1996 Titanium and titanium alloy bars[S]. Beijing: China Standards Press, 1996.
[8]	Huang Yongguang, Wang Yongmei, Xu Zhuping, et al. GB/T 6611-2008 Terminology and metallographs for titanium and titanium alloys[S]. Beijing: China Standards Press, 2008. (黄永光, 王永梅, 徐祝萍, 等. GB/T 6611-2008《钛及钛合金术语和金相图谱》[S]. 北京: 中国标准出版社, 2008. Huang Yongguang, Wang Yongmei, Xu Zhuping, et al. GB/T 6611-2008 Terminology and metallographs for titanium and titanium alloys[S]. Beijing: China Standards Press, 2008.
[9]	Feng Junning, Chen Zhanqian, Hu Zhijie, et al. GB/T 34647-2017 Temper designation system for titanium and titanium alloy[S]. Beijing: China Standards Press, 2017. (冯军宁, 陈战乾, 胡志杰, 等. GB/T 34647-2017《钛及钛合金产品状态代号》[S]. 北京: 中国标准出版社, 2017. Feng Junning, Chen Zhanqian, Hu Zhijie, et al. GB/T 34647-2017 Temper designation system for titanium and titanium alloy[S]. Beijing: China Standards Press, 2017.
[10]	Ma Zhongxian, Zhang Jiao, Xie Chen, et al. GB/T 38982-2020 dimensions, shape, weight and tolerances of titanium and titanium alloy bars and wires[S]. Beijing: China Standards Press, 2020. (马忠贤, 张佼, 解晨, 等. GB/T 38982-2020《钛及钛合金加工产品外形尺寸检测方法》[S]. 北京: 中国标准出版社, 2020. Ma Zhongxian, Zhang Jiao, Xie Chen, et al. GB/T 38982-2020 dimensions, shape, weight and tolerances of titanium and titanium alloy bars and wires[S]. Beijing: China Standards Press, 2020.
[11]	Hu Zhijie, Li Weiqing, Feng Junning, et al. GB/T 32185-2015 Titanium alloy large-sized bars[S]. Beijing: China Standards Press, 2016. (胡志杰, 李渭清, 冯军宁, 等. GB/T 32185-2015《钛合金大规格棒材》[S]. 北京: 中国标准出版社, 2016. Hu Zhijie, Li Weiqing, Feng Junning, et al. GB/T 32185-2015 Titanium alloy large-sized bars[S]. Beijing: China Standards Press, 2016.
[12]	Hu Zhijie, Feng Junning, Xie Chen, et al. GB/T 39799-2021 dimensions, shape, weight and tolerances of titanium and titanium alloy bars and wires[S]. Beijing: China Standards Press, 2021. (胡志杰, 冯军宁, 解晨, 等. GB/T 39799-2021《钛及钛合金棒材和丝材尺寸、外形、重量及允许偏差》[S]. 北京: 中国标准出版社, 2021. Hu Zhijie, Feng Junning, Xie Chen, et al. GB/T 39799-2021 dimensions, shape, weight and tolerances of titanium and titanium alloy bars and wires[S]. Beijing: China Standards Press, 2021.
[13]	Hu Zhijie, Li Weiqing, Feng Junning, et al. GJB 2218A-2018 Specification for titanium and titanium alloy bars and forging stocks for aircroft[S]. Beijing: National Military Standards Publishing and Distribution Department, 2019. (胡志杰, 李渭清, 冯军宁, 等. GJB 2218A-2018《航空用钛及钛合金棒材和锻坯规范》[S]. 北京: 国家军用标准出版发行部, 2019. Hu Zhijie, Li Weiqing, Feng Junning, et al. GJB 2218A-2018 Specification for titanium and titanium alloy bars and forging stocks for aircroft[S]. Beijing: National Military Standards Publishing and Distribution Department, 2019.
[14]	Huang Boyun, Li Chenggong, Shi Likai, et al.China materials engineering canon[M]. Beijing: Chemical Industry Press, 2006. (黄伯云, 李成功, 石力开, 等. 《中国材料工程大典》[M]. 北京: 化学工业出版社, 2006. Huang Boyun, Li Chenggong, Shi Likai, et al.China materials engineering canon[M]. Beijing: Chemical Industry Press, 2006.
[15]	Li Jian, Luo Ce, Lei Xiaoyan, et al. YS/T 1262-2018 Method for chemical analysis of titanium sponge, titanium and titanium alloys—Inductively coupled plasma atomic emission spectrometry[S]. Beijing: Metallurgical Industry Press, 2018. (李剑, 罗策, 雷小燕, 等. YS/T 1262-2018《海绵钛、钛及钛合金化学分析方法多元素含量的测定电感耦合等离子体原子发射光谱法》[S]. 北京: 冶金工业出版社, 2018. Li Jian, Luo Ce, Lei Xiaoyan, et al. YS/T 1262-2018 Method for chemical analysis of titanium sponge, titanium and titanium alloys—Inductively coupled plasma atomic emission spectrometry[S]. Beijing: Metallurgical Industry Press, 2018.
[16]	Wang Yanjun, Zheng Yanguan, Li Bo, et al. GB/T 4698 methods for chemical analysis of titanium sponge, titanium and titanium alloys[ S]. Beijing: China Standards Press, 2009. (王彦君, 郑炎官, 李波, 等. GB/T 4698《海绵钛、钛及钛合金化学分析方法》[S]. 北京: 中国标准出版社, 2021. Wang Yanjun, Zheng Yanguan, Li Bo, et al. GB/T 4698 methods for chemical analysis of titanium sponge, titanium and titanium alloys[ S]. Beijing: China Standards Press, 2009.
[17]	Liang Xinbang, Li Jiulin, Tao Liying, et al. GB/T 228-2002 Metallic materials-Tensile testing at ambient temperature[S]. Beijing: China Standards Press, 2002. (梁新邦, 李久林, 陶立英, 等. GB/T 228-2002《金属材料室温拉伸试验方法》[S]. 北京: 中国标准出版社, 2002. Liang Xinbang, Li Jiulin, Tao Liying, et al. GB/T 228-2002 Metallic materials-Tensile testing at ambient temperature[S]. Beijing: China Standards Press, 2002.
[18]	Zhao Junping, Li Jiulin, Zhu Tiezhu, et al. GB/T 4338-2006 Metallic materials-Tensile testing at elevated temperature[S]. Beijing: China Standards Press, 2006. (赵俊平, 李久林, 祝铁柱, 等. GB/T 4338-2006《金属材料高温拉伸试验方法》[S]. 北京: 中国标准出版社, 2006. Zhao Junping, Li Jiulin, Zhu Tiezhu, et al. GB/T 4338-2006 Metallic materials-Tensile testing at elevated temperature[S]. Beijing: China Standards Press, 2006.
[19]	Gao Yifei, Dong Li, Liu Tao, et al. GB/T 228.1-2021 Metallic materials - Tensile testing – Part 1: Method of test at room temperature[S]. Beijing: China Standards Press, 2021. (高怡斐, 董莉, 刘涛, 等. GB/T 228.1-2021《金属材料拉伸试验第1部分: 室温试验方法》[S]. 北京: 中国标准出版社, 2021. Gao Yifei, Dong Li, Liu Tao, et al. GB/T 228.1-2021 Metallic materials - Tensile testing – Part 1: Method of test at room temperature[S]. Beijing: China Standards Press, 2021.
[20]	Luo Jing, Gao Yifei, Zhao Junping, et al. GB/T 228.2-2015 Metallic materials - Tensile testing – Part 2: Method of test at elevated temperature [S]. Beijing: China Standards Press, 2015. (罗静, 高怡斐, 赵俊平, 等. GB/T 228.2-2015《金属材料拉伸试验第2部分: 高温试验方法》[S]. 北京: 中国标准出版社, 2015. Luo Jing, Gao Yifei, Zhao Junping, et al. GB/T 228.2-2015 Metallic materials - Tensile testing – Part 2: Method of test at elevated temperature [S]. Beijing: China Standards Press, 2015.
[21]	Mu Danning, Shi Wen, Li Jian, et al. GB/T 23605-2020 Determination of βtransus temperature of titanium alloys[S]. Beijing: China Standards Press, 2020. (穆丹宁, 史文, 李剑, 等. GB/T 23605-2020《钛合金β转变温度测定方法》[S]. 北京: 中国标准出版社, 2020. Mu Danning, Shi Wen, Li Jian, et al. GB/T 23605-2020 Determination of βtransus temperature of titanium alloys[S]. Beijing: China Standards Press, 2020.
[22]	Wang Yongmei, Feng Junning, Huang Yongguang, et al. GB/T 23604-2009 Methods of sampling for mechanical properties testing of titanium and titanium alloy products[S]. Beijing: China Standards Press, 2009. (王永梅, 冯军宁, 黄永光, 等. GB/T 23604-2009《钛及钛合金产品力学性能试验取样方法》[S]. 北京: 中国标准出版社, 2009. Wang Yongmei, Feng Junning, Huang Yongguang, et al. GB/T 23604-2009 Methods of sampling for mechanical properties testing of titanium and titanium alloy products[S]. Beijing: China Standards Press, 2009.
